| Gear series | 2 | 3 | 4 | 5 |
| Reduction ratio | 6. 10 | 18. 30 | 50, 60, 70, 75, 90, 100 | 120, 150, 180, 200, 250, 300 |
| Gearbox length (mm) | 21.2 | 23.7 | 26.2 | 28.7 |
| Maximum allowable continuous torque kgf.cm | 2 | 6 | 6 | 6 |
| Maximum allowable instantaneous torque kgf.cm | 6 | 18 | 18 | 18 |
| Efficiency% | 81 | 73 | 65 | 59 |
| Rotation direction (from drive to output) | Same | Opposite | Same | Opposite |
| The length of the motor | The total length of the motor depends on the specified motor | |||
| outer diameter dimension | 37mm | |||
| Gearbox type | Eccentric output shaft gearbox | |||
| Output shaft material | stainless steel | |||
| Output end bearing type | oil-impregnated bearing | |||
| Gear material | Powder metallurgy, machined steel teeth | |||
| Shell material | zinc alloy die casting | |||
| Working humidity range | 20%-85%RH | |||
| Working temperature range | -30℃~+100℃ | |||
| Our company can design and produce related products according to customer requirements | ||||
